Class 1 |
Horizontal & demonstrates little muscular
movement. Most favourable condition, as it allows more tissue coverage for
the palatal seal. |
Class 2 |
Soft palate makes 45° angle to the hard palate. Tissue coverage for
posterior palatal seal is less than that of class 1 condition. |
Class 3 |
Soft palate makes 70° angle to hard palate. Tissue coverage for posterior
palatal seal is minimum. A ‘V’ shaped palatal vault is usually associated
with class III soft palate. |
2. Classification of lateral throat form (retromylohyoid fossa):
Class 1 (deep) |
It indicates that the anatomical structure will
accommodate a fairly long and wind flange. Ideal throat form. |
Class 2 (moderate) |
It is about half as long and narrow as class 1 and
twice as long as class 3. |
Class 3 (shallow) |
Class III has minimum length of thickness. The
border usually ends 2-3 mm below the mylohyoid ridge. |
3. House classification of tongue size:
Class 1 |
Normal size, development and function. Sufficient
teeth are present to maintain this normal form. |
Class 2 |
Teeth have been absent long enough to permit a
change in the form and function of tongue. |
Class 3 |
Excessively large tongue. |
4. Wright's classification of tongue position:
Class 1 |
Tongue lies in the floor of the mouth with tip
forward and slightly below the incisal edges of the mandibular anterior
teeth. Ideal position of the tongue. |
Class 2 |
The tongue is flattened and broadened but the tip is
in a normal position. |
Class 3 |
The tongue is retracted and depressed into floor of
the mouth, with the tip curled upward or assimilated into the body of the
tongue. |
5. Stress bearing area of maxilla & mandible.
Movement |
Working condyle moves |
Laterotrusion |
Laterally and
outwards |
Laterosurtrusion |
Laterally and upwards |
Laterodetrusion |
Laterally and
downwards |
Lateroprotrusion |
Laterally and
forwards |
Lateroretrusion |
Laterally and
backwards |
7. Difference between closest speaking space & freeway space.
Closest speaking space |
Freeway space |
Described by Silverman |
Described by Thompson
and niswonger |
Closest speaking
space measures the vertical dimension when the mandible and muscles involved
are function of speech. It is the space between upper and lower teeth when
sounds like eh, s, j are pronounced |
It establishes
vertical dimension when the muscles and mandible are in rest position. |
It is dynamic
position established when muscles are in state of function. |
It is static position
established when muscles are in state of rest. |
It is about 1-2mm,
when measured in the premolar area |
It is about 2-4mm
when measured in the premolar area |
The speaking space
increases when there is small vertical dimension |
The freeway space
increases when there is reduced vertical dimension. |
8. Clinical features of increased & decreased vertical dimension.
Increased
vertical dimension |
Decreased
vertical dimension |
Decreased freeway space (Normal range= 2-4mm) Pain and clicking in the TMJ. Diffuse pain on ridge. Reversible soft tissue changes and irreversible
ridge resorption. Increased lower facial height. Cheek biting Stretching of facial muscles. |
Increased freeway space Sagging of the corners of the mouth Thinning of lips Obstruction of eustachian tube. Muscular imbalance Facial height decreases Angular cheilitis. |
9. Classification of articulators:
Class I (Simple holding instruments capable of accepting a
single static registration)
|
Eg: Slab articulators, Hinge joint,
Barndor, Gysi simplex. |
Class II (Instruments that permit horizontal as well as
vertical motion but do not orient the motion of TMJ via face bow transfer) |
Class IIa- Eccentric motion permitted based on average
or arbitrary values. Eg: Mean value articulator. Class IIb- Limited eccentric motion is possible based on theories
of arbitrary motion. Eg: Monson’s, Hall’s articulator. Class IIc- Limited eccentric motion is possible based on engraving
records obtained from the patient. Eg: House’s articulator. |
Class III (Permit horizontal, vertical positions and also
accept face bow transfer. |
IIIa- Accept a static protrusive registration
and they use equivalents for other types of motion. Eg: Hanau H, Dentatus. IIIb- They accept static lateral registration
and they use equivalents for other types of motion. Eg: Ney, Teledyne Haunau
University series, Trubite, Panadent. |
Class IV (They accept 3-dimensional dynamic registration) |
IVa- The condylar path registered cannot be
modified. Eg: TMJ articulator, stereograph. IVb- They allow customization of the condylar
path. Eg: Stuart instrument gnathoscope, pantograph, Denar. |
10. Treatment for deflective contacts in both anterior and posterior teeth.
Deflective contacts |
Occlusal correction |
Posterior teeth 1.Deflective contact is only in centric relation 2.Deflective contact is both in centric and
eccentric positions |
-Reduce fossa or marginal ridge -Reduce both fossa and cusp. |
Anterior teeth When incisal edge of lower anterior touching the
maxillary lingual fossa in centric relation only. |
Reduce the lower incisal edges. |
Incisal edge of lower anteriors touching the
maxillary lingual fossa both in centric and eccentric relations. |
Deepen the lingual fossa of upper teeth and reduce
the incisal edges of lower teeth. |
Deflective contacts occurring on working side |
BULLS law- Upper buccal cusp & lower lingual
cusp made shorter without deepening the central fossa. |
